Blind and buried vias are used to connect PCB layers where space is limited (high density PCB design) and are applied from the layer spans setting in the Design Technology dialog

Differential pairs carry two complimentary signals of the same magnitude but opposite polarity. The received signal is amplified and commonly used in high quality audio-video (A/V) applications.

In DSPCB, you can define a differential pair using Net Class settings and change their Gap and Skew length.

Ensure your design rules are matched and mitigate any costly manufacturing errors using DRC.

The BoM Composer helps simplify the task of producing the Bill of Materials ("BoM") as part of your production documentation. You can customise the BoM template to meet your needs and see changes in real time.

Export your PCB as a 3D model in the IDF format, which also features the component height values. After importing the IDF to DSM, you can build an enclosure for your PCB with knowledge of the maximum height of your components.

The BOM Quote will display the bill of materials for your current design or project including local price and availability from the latest online information.

The BoM can be loaded into your RS product basket on your local RS website, which you can then review, make substitutions on any out of stock or discontinued products, and checkout.

Flip an object over a mirror line or plane. Changes to the original object are applied to its associated reflection, and you can also isolate the mirror relationship to certain features.

Detail your designs in 2D engineering drawings with notes, geometric tolerances, hole tables, BoM tables, welding symbols and surface finish tool. DSM supports multiple industry standards for your annotations (ASME, JIS, ISO and GB) and conforms to the ASME Y14.5 standard for GD&T symbol creation.

Model-based definition provides greater clarity of datum / control features over 2D drawings for in-depth 3D visualization with MBD through semantic GD&T and 3D dimension annotations. Easily convey manufacturing requirements and reuse specific parts in multiple projects.

Use parametric equations to define custom curve patterns in 2D and 3D space, or choose from available curve types including Archimedes spiral, Catenary, Sine wave, Helix, Slinky, Spirals, Lemniscate (Bernoulli), Trochoid, Tractrix, Lissajous, and Viviani’s curve.

Apply constraints such as collinearity, tangency, and symmetry to create precise geometric relationships and use a construction line to mirror constrained features.

Choose from over one billion manufacturer approved part 3D models. Seamlessly insert into your current project or download for later use. Models are tagged with RS product codes so you can easily create a bill of materials and get a production quote.

Dedicated tools to check for errors, estimate size, mass, and volume of objects, display body interference and assess the quality of design surfaces by helping to identify anomalies.

Customise keyboard shortcuts, workspace views, rendering and shading settings, anti-aliasing, color schemes, toolbar layout etc. to make DSM suitable for day-to-day use.

Browse an extensive library providing hundreds of pre-defined components and models to help you get your online circuit designs started quickly. You can create models from scratch just as easily with our comprehensive circuit designer and simulator tool.

With the ability to share and embed “live” schematics and circuit simulator results, teams can collaborate more dynamically and interactively to enhance the design process. Whether you're an individual user or part of an engineering team, the DesignSpark Electronic Circuit Simulator has the functionality you need to streamline your project.

Our electrical circuit simulator tool is cloud-based, so you don't need to download anything to get started. Create an unlimited number of designs and save them all in the cloud for access when you need them and wherever you need them. All you need is a web browser and an internet connection!

Prototyping can be expensive and time-consuming. With our online circuit design and simulation tool, you can get the schematics just right so you can progress to the prototyping or production phase sooner and with more confidence.

Benefit from the hassle-free circuit creator and electronic simulator on DesignSpark to make your development process as easy as possible. You can design from scratch if you want full control or copy reference models to get you up and running in no time. Tinker with schematics until you're happy to simulate and see the results quickly with our practical waveform measurement and analysis features.
